APC Smart-UPS SRT 1500VA, 230V, 1.5kVA/1.5kW, Online Double-Conversion, Tower, Lead-Acid Battery, 6x IEC C13, 1.83m Cable, Black | SRT1500XLI

Main Input Voltage

230 V

Product or component type

Uninterruptible power supply (UPS)

Other Input Voltage

220 V

240 V

Main Output Voltage

230 V

Other Output Voltage

220 V

240 V

Rated power in W

1500 W

Rated power in VA

1500 VA

Input Connection Type

IEC 60320 C14

output connection type

6 IEC 60320 C13

Cable length

1.8 m

Number of cables

1

Provided equipment

CD with software

Communication cable

Documentation CD

Installation guide

Removable support feet

USB cable

Warranty card

Range of product

Smart-UPS On-Line

Batteries & Runtime

Run Time

View Runtime Graph

Battery type

Lead-acid battery

Battery voltage

48 V

Extended runtime

1

Number of battery filled slots

1

Number of battery free slots

0

Battery recharge time

3 h

Number of battery replacement quantity

1

Battery life

3…5 year(s)

Replacement battery

APCRBC155

Battery charger power

108 W rated

General

Number of power module filled slots

0

Number of power module free slots

0

product web sub-family

High density

Redundant

No

UPS type

Double conversion online

Physical

Colour

Black

Height

43.2 cm

Width

8.5 cm

Depth

50.5 cm

Product weight

20.5 kg

Mounting preference

No preference

Mounting mode

Rack-mounted with kit

Two post mountable

0

USB compatible

Yes

Mounting position

Vertical

Input

Input voltage limits

100...275 V

Network frequency

40...70 Hz auto-sensing

Output

Bypass type

Built-in bypass

Crest factor

3 : 1

Harmonic distortion

Less than 2 %

Maximum configurable power in VA

1500 VA

Maximum configurable power in W

1500 W

Wave type

Sine wave

Output frequency

50/60 Hz +/- 3 Hz sync to mains

Conformance

Product certifications

CE

EAC

UK PSTI

Standards

EN/IEC 62040-1:2019/A11:2021

EN/IEC 62040-2:2006/AC:2006

EN/IEC 62040-2:2018

Environmental

Acoustic level

50 dBA

Heat dissipation

317 Btu/h

Operating altitude

0...10000 ft

Ambient air temperature for operation

0…40 °C

Ambient air temperature for storage

-20…50 °C

Storage altitude

0.0000000000…15240.0000000000 m

IP degree of protection

IP20

Relative humidity

0…95 % non-condensing

Storage Relative Humidity

0…95 % non-condensing

Communications & Management

Emergency power off

Yes

Free slots

1

Alarm

Audible and visible alarms : prioritized by severity

Surge Protection and Filtering

Surge energy rate

432 J

Packing Units

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

24.5 cm

Package 1 Width

69.0 cm

Package 1 Length

59.5 cm

Package 1 Weight

32.58 kg

Contractual warranty

Warranty

3 years repair or replace (excluding battery) and 2 years for battery
