APC Smart-UPS SRT192RMBP, 192 V External Battery Pack, Rackmount 3U, Hot-Swappable Batteries, Black
SKU: 4336 Model: SRT192RMBP
6,290.00
In stock
- Free delivery by Tomorrow, Fri, Oct 30
- Bank transfer payment
- 1 Year warranty
- Free returns
The APC SRT192RMBP provides a 192 V external battery pack in a 3U rackmount chassis designed for Smart-UPS On-Line 5 kVA and 6 kVA models. Equipped with two hot-swappable lead-acid battery modules (APCRBC140), it supports easy replacement without downtime. Scalable runtime by cascading multiple units. Ideal for data centers and mission-critical IT environments. Includes rack rails and weighs approximately 91 kg
SRT192RMBP Features
APC Smart-UPS SRT 192V 5kVA and 6kVA RM Battery Pack
Extended-run battery systems provide flexible runtime to critical Smart-UPS applications.
Includes: Installation guide, Warranty card
- Hot-swappable batteries
- Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Smart-UPS Battery Systems Features & Benefits
Availability
Multiple battery pack configuration
Connect up to 10 battery packs for extended runtime applications.
| Brand | APC |
|---|---|
| Model | SRT192RMBP |
| Part number | SRT192RMBP |
| SKU | 4336 |
| Warranty | 1 Year |
| Weight | 91.00 kg |
| Dimensions | 43.50 x 13 x 68.50 cm |
Battery Output Voltage
192V
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Battery mounting
Stand alone battery stack
Expected Battery Life (years)
3 - 5
RBC Quantity
2
Battery blocks per string
--
Physical
Maximum Height
5.1inches (130MM, 13.0CM)
Maximum Width
17.0inches (432MM, 43.2CM)
Maximum Depth
26.88inches (682MM, 68.27CM)
Rack Height
3U
Net Weight
200.2lbs. (91.0KG)
Shipping weight
232.1lbs. (105.5KG)
Shipping Height
16.54inches (420MM, 42.0CM)
Shipping Width
23.63inches (600MM, 60.0CM)
Shipping Depth
39.38inches (1000MM, 100.0CM)
Color
Black
Units per Pallet
1.0
Environmental
Operating Temperature
32 - 104 °F (0 - 40 °C)
Operating Relative Humidity
0 - 95 (no %
Operating Elevation
0-10000ft (0-3000meters)
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 (no %
Storage Elevation
0-50000ft (0-15000meters)
Conformance
Approvals
OSHPD
Standard warranty
2 years repair or replace
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
Proposition 65 Warning
Available in Documentation tab
