APC Easy UPS 3S E3SUPS20KHB2, 20 kVA/20 kW, 400 V, 3-Phase, 3 Internal Battery Strings, VRLA, White
APC

APC Easy UPS 3S E3SUPS20KHB2, 20 kVA/20 kW, 400 V, 3-Phase, 3 Internal Battery Strings, VRLA, White

SKU: 9302 Model: E3SUPS20KHB2
AED37,200.00
In stock
  • Free delivery by Tomorrow, Fri, Oct 30
  • Bank transfer payment
  • 1 Year warranty
  • Free returns
Questions? Ask us on WhatsApp

The APC Easy UPS 3S E3SUPS20KHB2 delivers 20 kVA/20 kW power in a tower form factor with 400 V 3-phase input and output. It includes three internal modular 7 Ah VRLA battery strings (expandable), handles up to 37 A input current, and supports input frequency of 45–65 Hz. Designed for small to medium data centers, it offers robust protection with optional runtime expansion, LED display, and high reliability under demanding conditions .


Easy-to-install, easy-to-operate, easy-to-maintain, and easy-to-service 20 kVA, 400V 3-phase UPS With advanced product features, competitive specifications, and robust electrical design, the Easy UPS 3S UPS makes business continuity easy for small and medium data centers and electrical rooms Includes dust filter and conformance-coated boards for harsh environments, and 3 internal 7Ah modular battery strings


Easy UPS 3S is easy to install and start up


Parallel up to 4 UPSs for capacity or redundancy


Extended runtime options available


EcoStruxure IT: Enables resilient, secure, and sustainable IT environments


BrandAPC
ModelE3SUPS20KHB2
Part numberE3SUPS20KHB2
SKU9302
Warranty1 Year
Weight464.00 kg
Dimensions101 x 56 x 164 cm

Main Input Voltage

400 V 3 phases

Product or component type

Uninterruptible power supply (UPS)

Other Input Voltage

380 V

415 V

Main Output Voltage

400 V 3 phases

Other Output Voltage

380 V

415 V

Rated power in W

20 kW

rated power in VA

20 kVA

Provided equipment

Dust filter

Installation guide

Range of product

Easy UPS 3S

Batteries & Runtime

Efficiency


View Efficiency Graph

Battery type

VRLA

Battery voltage

240 V

Maximum short-circuit current

10 kA

Number of battery filled slots

3

Number of battery free slots

0

Physical

Colour

White (RAL 9003)

Height

140 cm

Width

38 cm

Depth

92.8 cm

Net weight

446 kg

USB compatible

Yes

Input

Maximum input current

37 A

Input harmonic distortion

Less than 3 % for full load

Load power factor

0.9 leading to 0.9 lagging

Input Power Factor at Full Load

0.99

Input voltage limits

304...477 V

Network frequency

45...65 Hz

Output

Maximum configurable power in VA

20 kVA

Maximum configurable power in W

20 kW

Output frequency

50 Hz sync to mains

60 Hz sync to mains

Harmonic distortion

Less than 3 %

Output harmonic distortion

< 3% linear load

Output voltage tolerance

+/- 1.5 %

UPS type

Double conversion online

Additional information

UPS weight does not include battery weight.

Conformance

Product certifications

CE

EAC

RCM

Environmental

Ambient air temperature for operation

0…40 °C

Relative humidity

0…95 % non-condensing

Operating altitude

0...3333 ft

Ambient air temperature for storage

-15…40 °C

Storage Relative Humidity

0…95 % non-condensing

Storage altitude

0.0000000000…15240.0000000000 m

Acoustic level

60 dBA

Heat dissipation

900 W

IP degree of protection

IP20

Packing Units

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

164 cm

Package 1 Width

101.4 cm

Package 1 Length

56.3 cm

Package 1 Weight

494 kg

Contractual warranty

Warranty

1 year on-site repair or replace with factory authorized Start-Up
