Main

Main Input Voltage

230 V

Main Output Voltage

230 V

Rated Power in W

375 W

Rated Power in VA

650 VA

Product Type

Uninterruptible power supply (UPS)

Input Connection Type

BS1363A British

Output Connection Type

4 universal receptacle

Cable Length

1.50 m

Number of Cables

1

Battery Type

Lead-acid battery

Provided Equipment

User manual

Batteries & Runtime

Efficiency

View Efficiency Graph

Number of Battery Filled Slots

0

Number of Battery Free Slots

0

Battery Life

3…5 year(s)

Replacement Battery

APCRBCV210

Extended Runtime

0

General

Number of Power Module Free Slots

0

Number of Power Module Filled Slots

0

Redundant

No

UPS Size

WS

Physical

Colour

Black

Height

9.25 cm

Width

16.5 cm

Depth

30.5 cm

Net Weight

4.5 kg

Mounting Preference

No preference

Mounting Mode

Not rack-mountable

Two Post Mountable

0

USB Compatible

No

Input

Network Frequency

50/60 Hz +/- 5 Hz auto-sensing

Input Voltage Limits

170...280 V

Output

Maximum Configurable Power in W

375 W

Output Frequency

50/60 Hz +/- 1 Hz unsynchronised

UPS Type

Line interactive

Wave Type

Stepped approximation to a sinewave

Graph Display

1

Maximum Configurable Power in VA

650 VA

Transfer Time

6 ms typical : 10 ms maximum

Conformance

Product Certifications

CE

Standards

EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018

Environmental

Ambient Air Temperature for Operation

0…40 °C

Relative Humidity

0…90 %

Operating Altitude

0...6667 ft

Ambient Air Temperature for Storage

-20…50 °C

Storage Relative Humidity

0…90 %

Storage Altitude

0…15240 m

Acoustic Level

40 dBA

IP Degree of Protection

IP20

Communications & Management

Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering

Surge Energy Rate

156 J
