BUSINESS ELEGANCE
The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance and high quality, while aiming to provide users incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency.
EXCLUSIVE FEATURES
CONNECTIVITY
THERMAL SOLUTION
Digital PWM
Pre-installed I/O Shield
Steel Armor II
EZ M.2 Shield Frozr II
6-layer Server-grade PCB with 2oz Thickened Copper
2x 8 Pin Power Connectors
EZ Conn Design
EZ PCIe Release
Power Delivery 27W
PCIe Supplemental Power
Thunderbolt 4
5G Network Solution
Latest Wi-Fi 7
DDR5 Support
Lightning Gen 5
7W/mK MOSFET Thermal Pads
Extended Heatsink
M.2 Shield Frozr
Pump Fan Support
MSI motherboards are designed with advanced hardware and technology, well-supporting the demanding computing usage of gaming and AI. Moreover, we also introduce AI to MSI Center and BIOS, making everything more effortless than before.
provides several categories for you to sync the applications you want to perform and automatically optimizing them to create a comfortable environment.
optimizes networking performance and minimizes latency, providing a seamless online experience.
automatically adjusts fan duty to make sure the system stays in cool, stable and high performance.
| Weight: | 1.00 kg |
| Dimensions: | 30X30X5 cm |
| Chipset INTEL Z890 | CPU Supports Intel® Core™ Ultra Processors (Series 2) |
| LGA 1851 | Memory 4x DDR5 UDIMM, Maximum Memory Capacity 256GB |
| Max. overclocking frequency | • 1DPC 1R Max speed up to 9200+ MT/s |
| • 1DPC 2R Max speed up to 7200+ MT/s | • 2DPC 1R Max speed up to 4800+ MT/s |
| • 2DPC 2R Max speed up to 4800+ MT/s | Supports Intel® POR Speed and JEDEC Speed |
| Supports Memory Overclocking and Intel® XMP 3.0 | Supports Dual-Controller Dual-Channel mode |
| Supports Non-ECC, Un-buffered memory | Supports CUDIMM |
| • Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https | Onboard Graphics 1x HDMI™ |
| Support HDMI™ 2.1 with FRL, maximum resolution of 4K 120Hz* | 2x Type-C DisplayPort |
| Thunderbolt™ 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz* | *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| Slot 3x PCI-E x16 slot | PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) |
| PCI_E2 Gen PCIe 4.0 supports up to x4 (From Chipset) | PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| Audio Realtek® ALC1220P | 7.1-Channel High Definition Audio |
| Supports S/PDIF output | Storage 4x M.2 |
| M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices | M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices |
| M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices | M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices |
| 4x SATA 6G | *Please refer to the manual for M.2 SSD heatsink restrictions. |
| RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices |
| Onboard Thunderbolt 2x Thunderbolt4 ports (Rear) | Support up to 40Gbps transfer rate with Thunderbolt devices |
| Support up to 20Gbps transfer rate with USB4 devices | Support up to 10Gbps transfer rate with USB 3.2 devices |
| Support up to 5V/3A,15W power charging | Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices |
| Support up to 8K display | USB 4x USB 2.0 (Front) |
| 4x USB 5Gbps Type A (Rear) | 2x USB 5Gbps Type A (Front) |
| 3x USB 10Gbps Type A (Rear) | 1x USB 10Gbps Type C (Rear) |
| 1x USB 20Gbps Type C (Front) | *USB 20Gbps Type-C (Front) support USB PD 27W fast charging for JUSBC1 |
| LAN Realtek® 8126 5Gbps LAN | Internal IO 1x Thunderbolt5 card connector(JTBT5, support RTD3) |
| 1x Power Connector(ATX_PWR) | 2x Power Connector(CPU_PWR) |
| 1x Power Connector(PCIE_PWR 8pin) | 1x CPU Fan |
| 1x Combo Fan (Pump_Sys Fan) | 6x System Fan |
| 1x EZ Conn-header (JAF_2) | 2x Front Panel (JFP) |
| 1x Chassis Intrusion (JCI) | 1x Front Audio (JAUD) |
| 3x Addressable V2 RGB LED connector (JARGB_V2) | 1x RGB LED connector(JRGB) |
| 1x TPM pin header(Support TPM 2.0) | 4x USB 2.0 ports |
| 2x USB 5Gbps Type A ports | 1x USB 20Gbps Type C ports |
| WIRELESS LAN & BLUETOOTH Intel® Wi-Fi 7 | The Wireless module is pre-installed in the M.2 (Key-E) slot |
| Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps | Supports 802.11 a/ b/ g/ n/ ac/ ax/ be |
| Supports Bluetooth® 5.4**, MLO, 4KQAM | * 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2. |
| ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2. | LED FEATURE 4x EZ Debug LED |
| 1x EZ Digit Debug LED | BACK PANEL PORTS |
| USB 10Gbps Type-A | USB 5Gbps Type-A |
| 5G LAN | Wi-Fi / Bluetooth |
| Audio Connectors | HDMI™ |
| Thunderbolt™ 4 40Gbps (Type-C) | USB 10Gbps Type-C |
| Flash BIOS Button | USB 5Gbps Type-A |
