Intel Core Ultra 9 285K 3.7 GHz LGA 1851 Processor, Intel Graphics, 24-Cores & 24-Threads, 40 MB Cache, 5.7 GHz Max | BX80768285K
| Weight: | 0.50 kg |
| Dimensions: | 15x10x10 cm |
| Total Cores 24 | # of PerformancTotal Cores 24 |
| # of Performance-cores8 | # of Efficient-cores16 |
| Total Threads 24 | Max Turbo Frequency 5.7 GHz |
| Intel® Thermal Velocity Boost Frequency 5.7 GHz | Intel® Turbo Boost Max Technology 3.0 Frequency ‡ 5.6 GHz |
| Performance-core Max Turbo Frequency 5.5 GHz | Efficient-core Max Turbo Frequency 4.6 GHz |
| Performance-core Base Frequency 3.7 GHz | Efficient-core Base Frequency 3.2 GHz |
| Cache 36 MB Intel® Smart Cache | Total L2 Cache40 MB |
| Processor Base Power 125 W | Maximum Turbo Power 250 W |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes | AI Software Frameworks Supported by CPUOpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
| CPU Lithography TSMC N3B | Supplemental Information |
| Marketing StatusLaunched | Launch Date Q4'24 |
| Embedded Options Available No | Use Conditions PC/Client/Tablet, Workstation |
| DatasheetView now | Memory Specifications |
| Max Memory Size (dependent on memory type) 192 GB | Memory Types Up to DDR5 6400 MT/s |
| Maximum Memory Speed6400 MHz | Max # of Memory Channels 2 |
| ECC Memory Supported ‡ Yes | GPU Specifications |
| GPU Name‡ Intel® Graphics | Graphics Base Frequency 300 MHz |
| Graphics Max Dynamic Frequency 2 GHz | GPU Peak TOPS (Int8) 8 |
| Graphics Output DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b | Xe-cores4 |
| Max Resolution (HDMI)‡ 4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL) | Max Resolution (DP)‡ 8K @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel)‡ 4K @ 60Hz | DirectX* Support 12 |
| OpenGL* Support 4.5 | OpenCL* Support 3 |
| Intel® Quick Sync Video Yes | # of Displays Supported ‡4 |
| Device ID0x7D67 | Intel® Deep Learning Boost (Intel® DL Boost) on GPU Yes |
| NPU Specifications | NPU Name‡Intel® AI Boost |
| NPU Peak TOPS (Int8) 13 | Sparsity SupportYes |
| Windows Studio Effects SupportYes | AI Software Frameworks Supported by NPUOpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
| Expansion Options | Direct Media Interface (DMI) Revision4 |
| Max # of DMI Lanes8 | Intel® Thunderbolt™ 4 Yes |
| Scalability1S Only | PCI Express Revision 5.0 and 4.0 |
| PCI Express Configurations ‡ Up to 1x16+2x4, 2x8+2x4, | 1x8+4x4 |
| Max # of PCI Express Lanes 24 | Package Specifications |
| Sockets Supported FCLGA1851 | Thermal Solution Specification PCG 2020A |
| Max Operating Temperature 105 °C | Advanced Technologies |
| Intel® Volume Management Device (VMD) Yes | Intel® Gaussian & Neural Accelerator 3.5 |
| Intel® Thread Director Yes | Intel® Speed Shift Technology Yes |
| Intel® Thermal Velocity Boost Yes | Intel® Turbo Boost Max Technology 3.0 ‡ Yes |
| Intel® Turbo Boost Technology ‡ 2.0 | Intel® 64 ‡ Yes |
| Instruction Set 64-bit | Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States Yes | Enhanced Intel SpeedStep® Technology Yes |
| Thermal Monitoring Technologies Yes | Security & Reliability |
| Intel vPro® Eligibility ‡ Intel vPro® Enterprise, Intel vPro® Platform | Intel® Threat Detection Technology (TDT)Yes |
| Intel® Active Management Technology (AMT) ‡ Yes | Intel® Standard Manageability (ISM) ‡ Yes |
| Intel® Remote Platform Erase (RPE) ‡Yes | Intel® One-Click Recovery ‡Yes |
| Intel® Hardware Shield Eligibility ‡ Yes | Intel® Control-Flow Enforcement Technology Yes |
| Intel® Total Memory Encryption - Multi KeyYes | Intel® AES New Instructions Yes |
| Secure Key Yes | Intel® Trusted Execution Technology ‡ Yes |
| Execute Disable Bit ‡ Yes | Intel® OS GuardYes |
| Intel® Boot Guard Yes | Mode-based Execute Control (MBEC) Yes |
| Intel® Stable IT Platform Program (SIPP) Yes | Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡Yes |
| Intel® Virtualization Technology (VT-x) ‡ Yes | Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ Yese-cores8 | # of Efficient-cores16 |
