QNAP 4 Bay Thunderbolt NAS Enclosure - Intel Pentium G5400T Dual-Core 3.1 GHz, With 4GB RAM, 10GbE, Gigabit Ethernet, M.2 PCIe NVMe SSD Slots, Up to 1158 MB/s File Transfer Speeds, Black | TVS-472XT

Powered by an 8th generation Intel® Pentium® Gold / Intel® Core™ i3/i5 processor, the high-performance TVS-472XT NAS features both 10GBASE-T and Thunderbolt™ 3 high-bandwidth connectivity for tackling heavy workloads and smoothly transferring, displaying and editing 4K videos in real-time. With M.2 SSD support and the ability to install a graphics card, the TVS-472XT provides the ability to boost performance and create a scalable working environment for collaboration and high-speed file sharing. The TVS-472XT is driven by high-quality hardware that delivers optimum performance, comprehensive multimedia features, expandable storage capacity, and numerous other NAS functionalities to inspire greater creativity and accomplishments!

1

High-speed Thunderbolt™ 3 with SMB protocol, perfect for collaboration on media editing.

2

5-speed 10GBASE-T RJ45 connectivity accelerates virtualization applications and file sharing across teams and devices.

3

PCIe expandability allows for graphics cards or 40GbE/ 25GbE/ 10GbE adapters to increase application performance.

4

Install M.2 PCIe (Gen 3 x2, 2 GB/s) NVMe SSDs (sold separately) to set up caching or storage pools, improving file access efficiency.

5

4K media playback and real-time transcoding; directly view creative works on an HDTV via HDMI™ 2.0 (4K @60Hz) output.

6

Snapshots fully record system status and data, allowing you to protect files and data from accidental deletion and malware attacks.

Fast and flexible Thunderbolt™ 3 and 10GBASE-T connectivity

The TVS-472XT provides options with the powerful 8th generation Intel® Pentium® Gold processor with 4 GB dual-channel DDR4 memory (upgradable to 64 GB), and Intel® Core™ i3/i5 processor with 4 GB dual-channel DDR4 memory (upgradable to 64 GB). It provides two Gigabit and one 5-speed 10GBASE-T port (10G/5G/2.5G/1G/100M), supports SATA 6Gb/s drives, and features AES-NI encryption for delivering high performance while also maintaining the security of your data. You can also connect USB Type-C devices through the Thunderbolt™ 3 ports to transfer large media files across devices, providing you with a more efficient workflow.

Note: Mac OS 10.11.5 (and later) enables SMB signing by default, which may impact the connection speed to the NAS. To improve the connection speed, users can disable SMB signing or use Qfinder Pro to connect to the NAS.

Extend NAS functionality with a graphics card and other PCIe devices

The TVS-472XT features two PCIe Gen 3 slots (the first slot is pre-installed with a Thunderbolt™ 3 card) that allow for the usage of various expansion cards to expand application potential.

Graphics cards

1. Accelerate NAS video processing and empower GPGPU tasks. GPUs can also be passed-through to virtual machines.
2.

QM2 M.2 SSD/10GbE cards

1. Add M.2 SSD caching or 10GbE (10GBASE-T) connectivity to the NAS for optimized performance and bandwidth.
2. Learn More: QM2, Qtier
3.

10GbE/ 40GbE adapters

1. Enable lightning-fast throughput for bandwidth-demanding tasks such as virtualization, massive data transmission, and fast backup/restoration.
2. Learn More: 10GbE NAS solutions
3.

Wireless network cards

1. Install a QXP-W6-AX200 Wi-Fi 6 wireless adapter to turn the TVS-472XT into a wireless NAS. Or make the TVS-472XT a wireless access point by installing the QWA-AC2600 wireless adapter and the WirelessAP Station app.

Flexibly manage virtual and physical networks

The Network & Virtual Switch app manages physical network interfaces (including network adapters and Thunderbolt™ ports) and virtual adapters (virtual machines and containers) and their communications, providing a visualized topology that clearly presents the connections of physical and virtual networks. The flexible manageability enables you to reorganize physical and virtual network connections with greater ease, so you can allocate adequate network resources to the TVS-472XT, virtual machines and containers whenever needed.
