Model Name

BT10(W-3-PK)

Network Standard

IEEE 802.11a

IEEE 802.11b

IEEE 802.11g

WiFi 4 (802.11n)

WiFi 5 (802.11ac)

WiFi 6 (802.11ax)

WiFi 6E (802.11ax)

WiFi 7 (802.11be)

IPv4

IPv6

Product Segment

BE18000 ultimate BE performance : 688+5764+11529 Mbps

WiFi Data Rate

WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps

WiFi 7 (802.11be) (5GHz): up to 5764 Mbps

WiFi 7 (802.11be) (6GHz): up to 11529 Mbps

Antenna

Internal antennas x 8

Transmit / Receive

2.4GHz 2x2

5GHz 4x4

6GHz 4x4

Processor

2.0GHz quad-core processor

Memory

RAM 2GB , Flash 256MB

Boosts Speed

OFDMA (Orthogonal Frequency Division Multiple Access)

Beamforming: standard-based and universal

4096-QAM high data rate

20/40/80/160/320 MHz bandwidth

Operating Frequency

2.4 GHz

5 GHz

6 GHz

Operating Mode

Wireless Router Mode

AiMesh Node Mode

Access Point Mode

I/O Ports

10G WAN/LAN x 1

10G LAN x 1

1G WAN/LAN x 1

USB 3.0 x1

Buttons

WPS button, Reset button, Power switch

LED Indicator

Power x 1

Power Supply

AC Input : 110V~240V(50~60Hz)

DC Output : 12V with max. 3A current

Package Content

ZenWiFi BT10

RJ45 cable

Power adapter

Warranty card

Quick start guide

Product Dimensions

159 x 72 x 186 mm

Remark

Content may vary in different regions and packages.

AiMesh

AiMesh

• Primary AiMesh Router

• AiMesh Node

Parental Control

"Allow you to block access to unwanted websites and apps."

Web & Apps Filters

Time Scheduling

Reward

Parental Control - Safe Browsing

Customized Internet Schedule

Router APP

APP: ASUS Router APP

Guest Network

"The Guest Network provides Internet connection for guests but restricts access to your local network."

Support Guest Network

Security

AiProtection

WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise

WPS

Let's Encrypt

DNS-over-TLS

Security Scan

Firewall

AiProtection

AiProtection Pro

• Router Security Assessment

• Malicious Site Blocking

• Two-Way IPS

• Infected Device Prevention and Blocking

VPN

Instant Guard

VPN Client L2TP

VPN Client Open VPN

VPN Client PPTP

VPN Client WireGuard

VPN Server IPSec

VPN Server Open VPN

VPN Server PPTP

VPN Server WireGuard

VPN Fusion

Traffic Control

Adaptive QoS

• Bandwidth Monitor

• Bandwidth Limiter

Traditional QoS

Traffic Monitor

Traffic Analyzer

• Website History

WAN

Dual WAN

3G / 4G LTE Dongle

4G / 5G Auto Mobile Tethering

Port Forwarding

Port Triggering

DMZ

DDNS

LAN

DHCP Server

IGMP Snooping

IPTV

LAN Link Aggregation

Manually Assign IP Address

Wake on LAN (WOL)

Wireless

MU-MIMO

UTF-8 SSID

WiFi MAC Address Filter

Wireless Scheduler

Airtime Fairness

RADIUS Client

Universal Beamforming

Explicit Beamforming

USB application

4G / 5G Auto Mobile Tethering

HDD Hibernation

Safely Remove Disk

AiCloud

Download Master

AiDisk

Media Server

Time Machine

Samba Server

FTP Server

Shared Folder Privileges

Administration

Diagnosis Tools

Feedback System

System Log

New Device Connect Notification

Login Captcha

Connection Diagnosis

Auto Firmware Update
