QNAP
21,899.00
QNAP TS-h1887XU-RP 18-Bay 4U Rackmount NAS - 2x3.5/2.5"+6x2.5" SATA Drive Bays, 3.4 GHz Intel Xeon E-2334 4C, 16GB ECC DDR4 RAM, 550W PSU, 10 Gigabit Ethernet Port, 3 PCIe | TS-h1887XU-RP-E2334-16G
SKU: 3920 Model: TS‑h1887XU‑RP‑E2334‑16G
21,899.00
In stock
- Free delivery by Monday, Nov 02
- Bank transfer payment
- 1 Year warranty
- Free returns
The high-capacity TS-h1887XU-RP is powered by a next-gen Intel® Xeon® E-2300 series processor, supports up to 128 GB DDR4 ECC memory, and provides an HDD/SSD hybrid storage architecture that balances performance and cost to deliver reliable server-grade performance. Running the ZFS-based QuTS hero operating system, the TS-h1887XU-RP emphasizes data integrity with inline data deduplication, near-limitless snapshots, real-time SnapSync, and QSAL (QNAP SSD Antiwear Leveling) – providing an ideal storage solution that meets today’s business requirements for file servers, virtualization servers, VDI, and backup/restore.
HDD/SSD hybrid storage
Combines the advantages of high-capacity HDD and high-performance SSD. Supports SSD caching to boost IOPS performance.
10GbE & 2.5GbE connectivity
Dual 10GBASE-T and dual 2.5GbE high-speed connectivity enhances virtualization, intensive file access, and large backup/restoration tasks.
High-speed PCIe Gen 4 slots
Install 10/25/100GbE adapters, QM2 cards, or Fibre Channel cards to increase application performance.
Virtualization applications
Supports virtualization storage and hosting virtual machines and containerized apps.
Comprehensive backup center
Optimized for business-class backup, including Google™ Workspace and Microsoft 365® data, and VMware® and Hyper-V virtual machines.
Cloud storage gateway
Realizes hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud.
Hybrid storage architecture, optimized for SSD cache acceleration
Compared with traditional storage arrays, the TS-h1887XU-RP hybrid storage balances cost, performance, and capacity. Featuring twelve 3.5-inch SATA 6Gb/s bays for hard drives and six 2.5-inch SATA 6Gb/s SSD slots, the TS-h1887XU-RP supports SSD caching to improve IOPS-intensive workloads for accessing vital data.
| Brand | QNAP |
|---|---|
| Model | TS‑h1887XU‑RP‑E2334‑16G |
| SKU | 3920 |
| Warranty | 1 Year |
| Weight | 19.00 kg |
| Dimensions | 90x70x40 cm |
CPU
Intel® Xeon® E-2334 4C 8T 3.4GHz, up to 4.8GHz
CPU Architecture
64-bit x86
Graphic Processors
Optional via a PCIe adapter
Floating Point Unit
Encryption Engine
(AES-NI)
System Memory
16 GB ECC DDR4 (1 x 16 GB)
Maximum Memory
128GB (4 x 32 GB)
Memory Slot
4 x ECC UDIMM DDR4
For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
18 (12 x 3.5-inch SATA + 6 x 2.5-inch SATA)
Drive Compatibility
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
2.5-inch bays:
2.5-inch SATA solid state drives
Hot-swappable
(Not supported M.2 SSD)
M.2 Slot
Optional via a QM2 PCIe adapter
SSD Cache Acceleration Support
GPU pass-through
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
2 (2.5G/1G/100M)
10 Gigabit Ethernet Port
2 x 10GBASE-T (10G/5G/2.5G/1G/100M)
25 Gigabit Ethernet Port
Optional via a PCIe adapter
Wake on LAN (WOL)
PCIe Slot
3 (2 x Gen4 x4 +1 x Gen 4 x8)
Card dimensions for PCIe slot 1：250 x 68.9 x 23.76 mm / 9.84 x 2.71 x 0.94 inches.
Card dimensions for PCIe slot 2：250 x 68.9 x 18.76 mm / 9.84 x 2.71 x 0.74 inches.
Card dimensions for PCIe slot 3：250 x 68.9 x 18.76 mm / 9.84 x 2.71 x 0.74 inches.
Wider cards can be installed if the next PCIe slot will not be used.
USB 3.2 Gen 2 (10Gbps) Port
4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps
HDMI™ Output
Optional via a PCIe adapter
Form Factor
2U Rackmount
LED Indicators
Status (Green/Red)
LAN (Green)
USB (Blue)
HDD status (Green/Red)
Buttons
Power, Reset
Dimensions (HxWxD)
88.6 × 432 × 511.2 mm
Weight (Net)
14.87 kg
Weight (Gross)
19 kg
Operating Temperature
0 - 40 °C (32°F - 104°F)
Storage Temperature
-20 - 70°C (-4°F - 158°F)
Relative Humidity
5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit
550W (x2) PSU
Power Consumption: Disk Standby Mode
118.77
Power Consumption: Operating Mode, Typical
148.94 W
Fan
4 x 60mm, 12VDC
Standard Warranty
5
Max. Number of Concurrent Connections (CIFS) - with Max. Memory
11000
